Victron SmartSolar MPPT RS 450/200-Tr
The SmartSolar MPPT RS 450/200 is the largest controller in the SmartSolar lineup. 450V max PV Voc, 200A max charge current on a 48V battery side. Two independent PV trackers, terminal block input, built-in display.
- Comms
- VE.Can, VE.Direct, Bluetooth, remote on/off
- Safety
- EN-IEC 62109-1
- Weight
- 13.7 kg
- Enclosure
- Steel, IP21
- Dimensions
- 487 x 434 x 146 mm
- PV terminals
- MC4 per tracker
About this product
The SmartSolar MPPT RS 450/200 is the largest controller in the SmartSolar lineup. 450V max PV Voc, 200A max charge current on a 48V battery side. Two independent PV trackers, terminal block input, built-in display.
200A charge current at 48V is roughly 10kW of solar feeding the battery bank, which puts this controller in the sweet spot for larger residential off-grid builds, full off-grid cabins running heavy loads, and small commercial installs where the array is sized to refill a big bank in a single sunny day.
VE.Direct and VE.Can comms tie it into the Cerbo GX and the rest of the Victron stack. Five-year Victron warranty.
