Iron Ridge HUG (No fasteners)
The HUG is IronRidge's flashing-free comp shingle mount. A cast aluminum halo presses an industrial foam-and-mastic seal flat against the shingle, sealing around the screw without prying or replacing the shingle above. Faster than traditional flash-and-flash mounts, and it works on bonded asphalt courses where lifting shingles can crack them.
In stock and ready to ship.
- Type
- Flashing-free comp shingle mount
- Listing
- UL 2703A
- Material
- Cast aluminum body + foam-mastic seal
- Warranty
- 25-year IronRidge
- Florida approval
- FL Product Approval #41858
- Fastener included
- No — pair with RD Structural Screw
About this item
The HUG is IronRidge's flashing-free comp shingle mount. A cast aluminum halo presses an industrial foam-and-mastic seal flat against the shingle, sealing around the screw without prying or replacing the shingle above. Faster than traditional flash-and-flash mounts, and it works on bonded asphalt courses where lifting shingles can crack them.
The seal conforms to the shingle surface and bridges step-downs up to 1/8". CertainTeed and Owens Corning have both approved HUG under their roof warranties. It's UL 2703A listed for flashing performance, and Florida Product Approval #41858 covers it under the FBC.
This SKU is the HUG body only, no fasteners included. Pair it with the IronRidge RD Structural Screw (also stocked here) to anchor through the deck, the rafter, or both. The RD screw passes through HUG's center channel and finishes the waterproof stack with an EPDM washer at the head.
Mount HUG into the rafter or the deck per the installation manual. Torque per IronRidge's spec; HUG is rated for the XR rail family and the FlashFoot2 / L-foot footprint.
