Victron MultiPlus-II 48/5000/70-95 120V
The MultiPlus-II 48/5000 in the 120V North American flavor. 48V battery side, 5000VA output (~4000W continuous), with a 70A charger and 95A transfer switch. Built for the higher-current loads typical on a US residential off-grid or hybrid install.
- Comms
- VE.Bus, 2x general-purpose port, remote on/off
- Output
- 120 VAC ±2%, 60 Hz
- Safety
- UL 1741, EN-IEC 60335, CSA 22.2
- Weight
- 71 lb (32 kg)
- Enclosure
- Steel, IP22
- Dimensions
- 26.6 x 13.0 x 6.5 in
About this inverter
The MultiPlus-II 48/5000 in the 120V North American flavor. 48V battery side, 5000VA output (~4000W continuous), with a 70A charger and 95A transfer switch. Built for the higher-current loads typical on a US residential off-grid or hybrid install.
Same PowerControl, PowerAssist, ESS support, and Cerbo GX integration as the rest of the II generation. Up to three of these in parallel gives you ~12kW continuous, which covers most whole-home loads outside of summer cooling peaks.
UL1741 listed for US grid-tied use. The 5000VA size is a common sweet spot for residential storage builds where the 3000VA is a little tight on transient loads (well pumps, big AC compressors) and the 8000 is more inverter than the design needs. Five-year Victron warranty.
