Victron MultiPlus 48/8000
The MultiPlus 48/8000 is the largest single-unit MultiPlus in the lineup. 48V battery side, 8000VA output, roughly 6400W continuous, with a 110A charger for putting energy back into a large battery bank quickly.
- Comms
- VE.Bus, 2x general-purpose port, remote on/off
- Safety
- EN-IEC 60335 / 62109
- Weight
- 42 kg
- Enclosure
- Steel, IP22
- Dimensions
- 642 x 363 x 206 mm
- Peak power
- 15,000 W
About this inverter
The MultiPlus 48/8000 is the largest single-unit MultiPlus in the lineup. 48V battery side, 8000VA output, roughly 6400W continuous, with a 110A charger for putting energy back into a large battery bank quickly.
This is the size of unit you'd reach for on a whole-home off-grid install where one machine handles the load instead of paralleling smaller units. PowerControl lets it share a limited shore or generator input without tripping breakers, and PowerAssist covers transient surges off the battery bank. Up to three of these can be paralleled for ~24kW of continuous capacity on bigger systems.
VE.Bus comms tie it to the rest of the Victron stack (Cerbo GX, MultiPlus-II if you're mixing, SmartSolar charge controllers). Five-year Victron warranty.
