MC4 Connector
A single MC4 connector. The standard connector used at module-to-module and module-to-string-wire joints across the solar industry. Locking design and a 600V DC rating that matches most modern module Voc.
In stock and ready to ship.
- Type
- MC4 PV connector (single)
- Locking
- Yes
- Sold as
- Individual
- Rule of thumb
- 3 per string (2 connections + 1 spare for botched crimp)
- Current rating
- Up to 30A (typical)
- Voltage rating
- 600V DC
About this item
A single MC4 connector. The standard connector used at module-to-module and module-to-string-wire joints across the solar industry. Locking design and a 600V DC rating that matches most modern module Voc.
Sold individually. The general rule for an array is 3 connectors per string (two for the string connections plus one spare for a botched crimp), plus extras for any home-run terminations and any future array expansion.
